Extra Heavy Duty Magnet Switches – Tiefenbach

tiefenbach_logo1“Tiefenbach – Extra Heavy Duty Magnet Switches, for Industrial, Mining & Off-shore industries, available in Weatherproof or Intrinsic Safe applications, in Monostable or Bistable.”

Continue reading Extra Heavy Duty Magnet Switches – Tiefenbach

Detecting Very Low DC Current Levels

DS1 – DC Current Sensor in a Compact, One-Piece Design for Detecting Very Low DC Current Levels.

DC-Interlock-DS1

The DS1 DC current switch is smaller than other DC current sensors and simpler to use. It is non-adjustable so the output closes when there is current and opens with there is no current. It uses the same circuit voltage to power the sensor as the circuit being controlled so it is easier to install than other sensors.

The DS1 current sensor can be powered by any DC voltage between 10 and 28 volts, and the solid state “contact” closes with a minimum of 0.75 amps DC through the sensing window. The contact can control a DC load up to one amp, up to 30 VDC.

Continue reading Detecting Very Low DC Current Levels

Q-16 Flow Switch Max RELIABILITY – Min COST

MODEL Q-16 Q16webThe “Harwil” Model  Q-16. Maximum Reliability at Minimum Cost.

The Q-16 is the newest addition to Harwil’s heavy-duty line of flow switches. The switch is used to signal, start, or stop electronically operated equipment when flow or no-flow conditions occur. The Q-16 benefits from 40 years of flow switch development experience for every conceivable application.



Continue reading Q-16 Flow Switch Max RELIABILITY – Min COST

American Aerospace Controls-AAC

Premier manufacturer’s of AC & DC current, voltage, power and frequency transducers since 1965. American Aerospace Controls is a company dedicated exclusively to the design and manufacture of electrical transducers for high reliability defense, aerospace and space flight applications. Our unique in-house testing for manufacturing and development meets Space Flight, Mil Grade, EMI Standards and DO-160 for reliability. The inherent quality levels of our manufacturing in compliance with ISO 9001 and AS9100 provides rail transit, commercial and industrial markets with standard catalog products produced in a high reliability environment. These markets benefit from customized products to meet specific needs that are not readily available.

Feature Product:

DC Current Transducer:  Series 920
Output: 4-20mA
(2-Wire, loop power)
Closed-Loop Technology
Superior Accuracy and Stability
Over Wide Temperature Range
Automating & updating measurement and control functions in existing systems.
Local & remote station power & battery back-up current monitoring.
Field service, maintenance & trouble shooting DC systems.
DC current sensing in laboratory experiments and special projects.

Specification:
INPUT Accuracy
P/N: 920-50 0 to +50Adc 1.25%FS See
P/N: 920-75 0 to +75Adc 1.0%FS Note
P/N: 920-100 0 to +100Adc 1.0%FS (1)
P/N: 920-125 0 to +125Adc 1.0%FS
Continuous Overload………………±5000Adc
OUTPUT
Current Signal………………………..4 to 20mAdc
Current Signal @ Overload………24mAdc (typical)
Accuracy (Over –40 to +85°C)….See above table & Note (1)
Response Time (10 to 90%)…….10milli-seconds
Load Resistance…………………….250Ω nominal (0 to 300Ω)
Protection………………………………Reverse Polarity Protected
POWER SUPPLY
Supply Voltage……………………….+24Vdc (+18 to +28Vdc)
Current Drain………………………….4 to 24mAdc
Voltage Transient……………………±40V T< 5mS
ENVIRONMENTAL & PHYSICAL
Operating Temperature……………-40 to +85°C
Storage Temperature………………-45 to +85°C
Isolation (Input to Output)………..2kV rms @ 60Hz / 1min
Insulation Resistance………………500MΩ @ 500Vdc
Molded Plastic Case……………….UL Flammability rating 94V-O
Weight…………………………………..14 oz max
Finish (Blue Texture)……………….Panatone No. 294C
Note (1): Accuracy includes combined worst-case effects of: zero offset; temperature; hysteresis; supply swings and current cable position.
