Trumeter 795x – 8 or 18 function Time Relay

7957-2
7957-24 to 240VAC/VDC



Trumeter’s new range of 795X digital time relays offer 8 (7954) or 18 (7957) operating modes, easily configured on the 3 digit LCD

display; a wide timing range of 0.1s – 999Hr to suit all applications; a clear indication of the changeover relay

status via the front panel LED; can accept a wide range of operating voltages for most installations. The key

lock feature means settings cannot be tampered with, meaning 100% reliable operation.

Features

  • Compact 17.5mm DIN rail mountable
  • 3 digit LCD for easy programming
  • Tamper proof with key lock feature
  • Wide timing range: 0.1s – 999Hr
  • Multi-function: (8 or 18) non-signal and signal based functions
  • Multi-voltage: 24 – 240VAC/VDC
  • Option to select up/down counting
  • CE, Ul & cUl approved

Operating Modes:

  • ON Delay
  • Cyclic OFF/ON
  • Cyclic ON/OFF
  • Impulse on Energising
  • Accumulative Delay on Signal
  • Accumulative Delay on Inverted Signal
  • Accumulative Impulse on Signal
  • Signal ON Delay
  • Inverted Signal ON Delay
  • Signal OFF Delay
  • Impulse ON/OFF
  • Signal OFF/ON
  • Leading Edge Impulse 1
  • Leading Edge Impulse 2
  • Trailing Edge Impulse 1
  • Trailing Edge Impulse 2
  • Delayed Impulse
  • Inverted Signal ON Delay (Type 2)
